5/8" (M16) Round Punch & Die Set

Product Features

• Round punch and die set that produces a 0.69" (17.5 mm) hole — sized for standard 5/8" (M16) bolts
• Matched punch and die machined as a pair for burr-free holes and clean shear
• Designed for the Enerpac SP-35 35-ton hydraulic punch
• Hardened tool steel construction for long life in repeat punching
• Punches mild steel up to 1/2" (13 mm) thick when used with the SP-35
• Bridges both inch and metric work — this is the 5/8" / M16 crossover size, included in both the SP35S standard die set and the MSP351 metric die set
• No lubrication required — keep the punch and die clean and they run as intended
• Die installs with the larger opening facing down; punch installs with the long stem facing down
• Quick changeover — remove the cap nut, pull the punch, swap the die in the lower jaw
• Replacement / add-on tooling for contractors who already own an SP-35 punch
• Genuine Enerpac OEM tooling for correct punch-to-die clearance

Specifications

• SKU: ENESPD688
• Price: 274.13
• Weight: 15.00 lbs
• Dimensions: 11.50 L x 4.80 W x 3.50 H (inch)
• Style: Punch and Die Set, Round / Circle Hole Shape
• Brand: Enerpac
• Model / Cat. No.: SPD688
• Series: SPD
• Hole Shape: Round
• Hole Diameter: 0.69 in (17.5 mm)
• Bolt Size: 5/8 in (M16)
• Compatible Punch: Enerpac SP-35 (35 ton) hydraulic punch
