Greenlee BENDER,ELECTRIC CONDUIT(855GX) (855GX)

Product Features

• 12 ton hand-held battery hydraulic crimping tool for aluminum and copper connectors on electrical cable
• Dieless design crimps 4 AWG – 1000 kcmil copper and 6 AWG – 1000 kcmil aluminum with no dies to change
• Flip-top head opens for easy placement on in-place conductors
• Crimping head rotates 350° for access in tight enclosures and manholes
• One trigger controls all tool functions
• Monitors crimping pressure 32 times per second to confirm proper force on every crimp
• Alerts the operator visually and audibly if a cycle is not completed correctly
• Automatically retracts the ram to signal the crimp is complete
• Automatic Retraction Stop (ARS) retracts the ram only as far as needed for the next crimp, saving cycle time
• Retraction Stop Repeat (RSR) lets the operator hold a partial retraction across repeated crimps
• Two-stage hydraulic system gives fast advance and high-force crimping speeds
• Bluetooth connectivity through the Gator Eye app for tool data and maintenance tracking
• LED light shows battery charge and tool maintenance status
• Pistol-style handle with over-molded rubber grip
• C/US UL Listed
• Part of Greenlee's Gator dieless crimping tool line

Specifications

• Style: Battery Hydraulic Dieless Crimping Tool
• Brand: Greenlee
• Series: EK12IDLX (Gator)
• Model / Cat. No.: EK12IDLX11
• Greenlee Catalog No.: 52078748
• Crimping Force: 12 ton — 24,000 lb (106 kN)
• Crimping Capacity: 1000 kcmil (MCM) copper and aluminum
• Wire Size Range: 4 AWG – 1000 kcmil Cu; 6 AWG – 1000 kcmil Al
• Die Requirement: None (dieless)
• Head Style: Flip top, rotates 350°
• Connector Type: Color-coded lugs and splices
• Hydraulic System: Two-stage
• Connectivity: Bluetooth via Gator Eye app
• Handle: Pistol style with over-molded rubber grip
• Overall Length: 16.5 in (420 mm)
• Power Configuration: Battery, with 120 V charger
• Batteries: 2 included
• Charger: 120 V included
• Includes: Crimping tool, (2) batteries, charger, case
• Corded Operation: Optional AC adapter EAC18120 (120 V) or EAC18230 (230 V), sold separately
• Standard: C/US UL Listed
• UPC: 783310611349
• Greenlee Benefit: Dieless 12 ton crimper that covers 4 AWG–1000 kcmil without a single die change, and self-checks force 32 times a second on every crimp
