Greenlee Cable Feeding Sheave (441-2)

Greenlee model 441-2 is the Feeding Sheave for 2" Conduit. Yoke frame slides into the end of conduit and holds sheave, allowing the cable being fed into the conduit to smoothly roll over the sheave. 5 in (127 mm) wide aluminum alloy sheave with self-Lubricating bearings.

• Manufacturer part number: 441-2
• GTIN (UPC): 0783310301837
• Keyway: None
• Material: Feeding Sheave for 2" conduit
• Includes: 25160 Sheave Pin, 50302 Sheave Pin Clip (2), 15362 Sheave
• Standard: Feeding Sheave for 2" conduit
• Type: Sheave Assembly
• Application: Electrical Cable Feeding
• Capacity: 1,750 lb (7.7 kN) At 15 DEG, 900 lb (4 kN) At 30 DEG, 650 lb (2.8 kN) At 45 DEG, 500 lb (2.2 kN) At 60 DEG, 450 lb (2 kN) At 75 DEG, 450 lb (2 kN) At 90 DEG
• Split tube for easy removal after cable is installed
