GreenLee

Greenlee TEMPO Buried Line Locator BLL-200

Greenlee TEMPO Buried Line Locator BLL-200

SKU:GRNBLL-200

Regular price $2,441.88
Regular price $2,441.88 Sale price $2,441.88
Sale Sold out
Shipping calculated at checkout.

    Product Features

    • Trace buried conductors.
    • Measure depth of buried conductors.
    • Follow and mark precise routes of utilities.
    • Lightweight and ergonomically balanced.
    • Automatic signal boost makes it easy to trace lines, even those with very week signals.
    • Microprocessor-based circuitry delivers increased accuracy and features auto-gain control in all environments.
    • LED and LCD signal strength indicators make it quick and easy to find exact line location.
    • Avoid damaging services when digging; survey before excavating.
    • Receiver may be used in active or passive mode.
    • Receiver locates multiple passive frequencies with a single setting.
    • Receiver automatically locks out passive range when it detects a transmitter signal, reducing the chance of tracing other lines carrying weaker signals.
    • Traces 20' (6 m) underground and provides depth readings up to 15'.
    • Transmitter can be connected to live lines up to 600V.
    • Molded carrying case included.

    Specifications

    • Battery: 6 V (4 AA) for transmitter and receiver
    • Current: 13 mA (open line), 150 mA (live or shorted line) — transmitter
    • Depth Range:
    • 0–15 ft measurement (±10% reading + 0.200 ft)
    • 0–20 ft tracing (±10% reading + 0.200 ft) — receiver
    • Depth Resolution: 0.100 ft increments
    • Dimensions:
    • Transmitter: 7.500 in (190.5 mm) x 4.000 in (101.6 mm) x 2.100 in (53.0 mm)
    • Receiver: 4.100 in (104.1 mm) x 8.500 in (215.9 mm) x 38.000 in (965.2 mm)
    • Frequency: 33.3 kHz — transmitter
    • Operating Voltage: 0–600 VAC, 0–300 VDC — transmitter
    • Passive Trace Frequency: 12 Hz–24 kHz
    • Storage/Operating Temperature: 0–270 °F (–17 to 50 °C) — transmitter and receiver
    • Weight:
    • Transmitter: 15 oz (425 g) with batteries and clamp
    • Receiver: 1.750 lb (794 g)
