PUNCH, 1" CONDUIT (744) SC

Product Features

• Slug-Splitter SC® self-centering knockout punch for 1 in. conduit size
• Self-centering design aligns itself on the pilot hole — no crosshairs to draw, no die alignment marks to line up
• Unique punch profile splits the slug for faster, easier slug removal
• Punches through up to 10 gauge (3.5 mm) mild steel and stainless steel
• Tool steel construction for repeated heavy-duty use
• Good abrasion resistance for punching fiberglass and plastic enclosures as well as steel
• Matches Greenlee die 28159 to form a complete punch unit
• Works with battery-powered, hydraulic, and high-leverage ratchet drivers
• Replacement punch — for rebuilding or expanding an existing knockout set
• Part of Greenlee's Slug-Splitter SC® knockout line

Specifications

• Style: Knockout Punch (Round, Self-Centering)
• Brand: Greenlee
• Sub-Brand: Slug-Splitter SC®
• Model / Cat. No.: 28158
• Conduit Size: 1 in
• Actual Hole Size: 1-11/32 in (1.362 in)
• Material Capacity: Up to 10 gauge (3.5 mm) mild steel and stainless steel
• Punch Material: Tool steel
• Punch Shape: Round
• Corresponding Die: 28159 (sold separately)
• Corresponding Draw Studs: 31872 (hydraulic drivers 7804, 7904); 29452 (hydraulic drivers 7646, 7625); 12099 (ratchet driver 1904)
• Compatible Drivers: Battery, hydraulic, or high-leverage ratchet driver only
• Used On Punch Unit: 745H-1
• Includes: Punch only — die and draw stud sold separately
• UPC: 0783310281580
• Warranty: Greenlee warranty and return policy applies
• Greenlee Benefit: Self-centering 1" conduit punch that lands on the pilot hole without layout marks and splits the slug for quick removal
